Breaker AC Din Rail 2P Chontig

Specifications

product type      AC Miniature Circuit Breaker 120V/240V 40Amp

Rated Operational Voltage          DZ47 AC 120 V / 240 V (optional)

Poles     2P

Rated Current [In]           10 A / 16 A / 20 A / 25 A / 32 A / 40 A / 50 A / 63 A (optional)

Standard              IEC60898-1

Mounting Support           35mm DIN rail

Operating Temperature                -13°F(-25℃) ~ 140°F(60℃)

Mechanical Durability     10000 Cycles

Electrical Durability          2000 cycles

Tightening Torque           2.5 N.m

Uimp     4kV

Breaking Capacity            6kA Ics=Icu

Package Includes             1 x AC miniature circuit breaker, 1 x DIN rail, 2 x screws
